THERMASOLV IM2
- Dielectric heat transfer fluid
- Boiling point: 49°C/120°F
- Non-flammable & ultra-low GWP
THERMASOLV IM2 is a dielectric heat transfer fluid, dedicated for 2-phase immersion or direct cooling systems. Its high electrical insulation properties allows to immerse electronics & electrical devices under power in the fluid. The favorable characteristics of the product’s viscosity, density and surface tension allows optimal surface contact, which contributes to a superior heat transfer performance.
The very good compatibility with all metals, a wide range of plastics & elastomers and the chemical stability of the fluid, makes THERMASOLV IM2 an ideal fluid for immersion cooling.
THERMASOLV IM2 is formulated with safety in mind. It is non-toxic, has no mentioning of any EUH-phrases, is non-flammable and has no flash point. It also has fire extinguishing properties, which provides extra protection in case of fire. It is also a great sustainable solution as it has no ODP, ultra-low GWP (<10) and can be offered for recycling when needed.
Show links
Hide linksThis is a product
MAIN CONTRIBUTORS WHICH REDUCE IMPACT:
HUMAN HEALTH & SAFETY
- Non-flammable, no flashpoint & no EUH risk phrases: 100% safe for storage and when used in equipment
- Non-toxic, no corrosive impact & no S risk phrases
ENVIRONMENT PROTECTION & RESOURCES SAVINGS
- No environmental hazard: no H labelling regarding environment
- Can be returned for recycling and re-use: ECOPROGRAM
- Ultra-low GWP
Benefits
Performance
- Excellent thermal conductivity
- Very low surface tension
- High electrical insulation
- Low kinetic viscosity & low freezing point limit the load on pumps
Cost
- Thermally and chemically stable in use
- Can be returned for recycling and re-use
HSE
- Ultra-low Global Warming Potential (GWP): <10
- No Ozon depletion potential (ODP)
- Non-flammable
- Low environmental impact: GREENWAY product
Process information
Processes
The best process will depend on factors such as operating conditions & equipment. Our team is ready to advise you.
This product is not suitable when there is a high risk of contact with water as it degrades the performance of the product and its functionality.
Although this product has very good compatibility properties, we cannot foresee all materials that could be exposed to the fluid. We strongly recommend testing before use.
The product can be used in the following processes:
- Immersion cooling (only 2-phase)
- Direct cooling, where the fluid flows through cold plates or tubes (only 2-phase)
- Specific manufacturing processes which need stable and uniform cooling
- Dielectric testing
Temperature limits
2-phase system
- Boiling Point: 49°C / 120°F
